Karrier Motors Limited
Fate purchased by Commer (Rootes Group) 1934
Successor Dodge (Chrysler)
Founded 1908
Defunct 1979
Headquarters Huddersfield, England
Luton, England
Key people
  • Herbert Clayton, (founder)
  • Reginald Clayton
Industry Automotive industry (Commercial vehicles)
Products
  • medium goods vehicles
  • light goods vehicles
  • municipal cleansing equipment
  • trolleybuses
  • fire appliances
  • mechanical horses
Parent
Karrier Bantam

Karrier Bantam c. 1952

Karrier is a marque of car and commercial vehicle, the origins of which can be traced back to Clayton and Company, a 1904 company from Huddersfield, West Yorkshire, UK. They began making Karrier motor vehicles in 1908 in Queen Street South, Huddersfield. In 1920, H.F. Clayton sold Clayton and Co's Huddersfield business into public listed company Karrier Motors while keeping their Penistone operation separate and mechanical and electrical engineers Clayton & Co Penistone remains active in 2015.

Karrier produced buses as well as their other municipal vehicles and in latter years, especially during the Second World War, Trolleybuses, notably their Karrier 'W' model.

In 1934 Karrier became part of the Rootes Group where it retained its brand identity though the business was operated as part of Rootes' Commer commercial vehicle operation. The Karrier name began to disappear from products when Chrysler bought Rootes in 1967. It was finally dropped in the early 1970s.

Ownership[]

Clayton and Co[]

Herbert Fitzroy Clayton (1857–1935), a prosperous chemicals manufacturer or drysalter and dyer,[1][2] incorporated in December 1904 a company, Clayton & Co Huddersfield Limited, to own the engineering business he had carried on independently since 1899[note 1] when he had left his Dixon Clayton & Co partnership.[3] In 1908,[4] joined by his second son, Reginald Fitzroy Clayton MIAE (1885–1964), Clayton & Co began designing and making Karrier petrol driven motor vehicles and charabancs which became their main business. In 1920,[5] keeping Clayton & Co Penistone separate and retaining control of this new company,[6] Clayton & Co Huddersfield was sold to a newly incorporated public listed company which they named Karrier Motors Limited.[5] At this time the products had been:

Karrier motor lorries vans and wagons and motor charabancs
Fog signalling machines and detonators, Clayton Certainty Railway Fog Signal, (manufactured at Huddersfield, 68 Victoria Street, London SW1 and Westhorpe, Penistone, Yorkshire) which remained with Clayton & Co Penistone
Patents for and to manufacture the (yet to go into production) Karrier Combined Motor Roadsweeper, Sprinkler and Refuse Collector providing sanitary street cleansing in an economical manner[5]
Karrier Motors Limited

Karrier experienced financial difficulties and suffered substantial losses in the late 1920s.[7][8][9]

A plan to amalgamate T.S. Motors Limited (Tilling-Stevens) with Karrier agreed in August 1932[10][11] was dropped a month later without explanation.[12] The following August 1933 Karrier tardily announced that under difficult trading conditions they had made a substantial loss during that 1932 calendar year.[13] At the beginning of June 1934 Karrier was put into receivership though it was also announced that business would continue while "negotiations" were completed.[14] It was bought by Rootes.


History[]

In 1908 they started making Karrier cars and in 1920 changed the company name to Karrier Motors Ltd.

Rootes group[]

Karrier Ladder Fire Engine (8631547637)

1961 Gamecock water tender

MR WHIPPY KARRIER ICE CREAM VAN ORIGINAL AT THE ALBERT DOCK LIVERPOOL MAY 2013 (8717643464)

1961 Karrier van; Mr. Whippy Ice Cream—original at the Albert Dock Liverpool, UK in May 2013

Bradford Trolleybus 735 at Black Country Living Museum - geograph.org

Bradford Trolleybus 735 (1946) at Black Country Living Museum

After takeover bids in 1934, the Rootes group acquired Karrier into its fold and moved production to Luton, closing the Huddersfield operation. In the late 1950s and 1960s some Karrier vehicles were fitted with the inconic Rootes two-stroke opposed piston diesel engine, see Commer. Other engines used in this period include Humber Hawk petrol engines (L Heand and OHC) and Perkins Diesels.

At Luton, the only designs carried over from the previous era were the three wheeler and the six-wheel trolleybus chassis.

The trolleybus business became integrated with that of Sunbeam Commercial Vehicles Limited following Sunbeam's purchase by the Rootes group. In 1946 J. Brockhouse and Co Limited of West Bromwich, the engineering group, bought Sunbeam Commercial Vehicles but sold the trolley-bus part of the business to Guy Motors Limited in September 1948.[15]

Under Rootes ownership, Karrier trucks were generally smaller size than their sister, Commer brand, with "Bantam" models using 13-inch and "Gamecock" models using 16-inch wheels, to give lower loading height. They were designed for local authorities and their varied applications, including highway maintenance tippers, refuse collection vehicles and street lighting maintenance tower wagons. Karrier trucks and chassis were also built for and supplied to airport operators and airlines for baggage handling trucks, water bowsers and toilet servicing.


Dodge (UK)[]

The Dodge Brothers company came to the UK in 1922 and began importing United States Dodge "knocked-down" kits to build in the UK at a production line in Park Royal, London. Eventually production was moved to the Chrysler plant at Kew; the Dodges built there were known as "Dodge Kews".

In 1965 production moved to Dunstable where Commer, Dodge (UK) and Karrier were all brought together.


Chrysler Europe[]

By 1970 the Rootes Group had been taken over (in stages) by Chrysler Europe, with support from the British Government which was desperate to support the ailing British motor industry. The Dodge brand, (also used by Chrysler in the USA), began to take precedence on all commercial models. The last vestige of Karrier was probably in the Dodge 50 Series, which began life badged as a (Chrysler) Dodge but with a Karrier Motor Company VIN (Vehicle Identification Plate) plate.

Peugeot and Renault[]

Chrysler eventually gave up on UK operations, selling the business to Peugeot. The new owner had little interest in heavy trucks and the factory was then run in conjunction with Renault Véhicules Industriels, (then part of Renault/Renault Trucks (now part of Volvo Trucks). The combined company used the name Karrier Motors Ltd[16], although the vehicles took on Renault badges and were sold through Renault Trucks dealers. Renault had been keen to secure a UK manufacturing operation for engines for its own models, and did relatively little to market or develop the British designs, favouring its existing French range such as the Renault Master. The end of the Karrier name could not be far off; eventually Renault severed ties with Peugeot[citation (source) needed] and introduced a Renault Truck Ind. or Renault Vehicles Ind. VIN Plate.

The Karrier trademark is still in the possession of Peugeot, and it is not uncommon for vehicle marques to be reinstated.


Products[]

Light tractor units[]

Colt
Karrier Cob (1930) (4667565504)

Cob, National Rail Museum, York

Stockport Corporation recovery vehicle (YM9410)

Stockport Corporation recovery vehicle—in service 1926–1970

In 1929, Karrier started production of the "Colt" three-wheeler as a dustcart chassis for Huddersfield Corporation. In 1930, this was developed into the "Cob" tractor to haul road trailers for the London, Midland and Scottish Railway.

Later, in 1933, Scammell produced their own, Napier designed, Scammell Mechanical Horse.

In the mid-1930s, the "Cob" range was supplemented by the four-wheel "Bantam".

Cob

Described by newspapers, quoting Karrier, in 1930[17] as a "mechanical horse" the small "Cob" tractor was designed by J Shearman, road motor engineer for London, Midland and Scottish Railway. Its small wheels let it turn in confined spaces and manoeuvre more easily in traffic. The front wheels are lifted from the ground when the tractor is attached and it was then classed as an articulated vehicle. It was capable of pulling a three-ton load at 18 mph and capable of restarting on a gradient of one in eight.[18] Production tractors powered by Jowett engines were displayed on the Karrier stand at Olympia's Motor Transport Show. A Karrier "Cob" Major, a 4-ton three-wheeled tractor, was also displayed[19]

Ro-Railer[]

Karrier's Ro-Railer was a hybrid single decker bus, capable of running on both road and rail, intended for towns and villages distant from a railway. Also designed by J Shearman, road motor engineer to London, Midland and Scottish Railway it was tested by the chairman and board of directors of LM & S in January 1931 by travelling between Redbourn and Hemel Hempstead.[20]

Though it was not a success,[21][22] Karrier's road railbus looked like a bus and could be changed from road to rail in 2½ to 5 minutes. With a six-cylinder engine and a body by Craven it ran at up to 50 mph. Said to be very rough-riding it ran for 1930/31 on the Stratford-on-Avon and Midland joint line. Finally it became a ballast vehicle on the West Highland Line.[23]

Trolleybuses[]

In 1925, Karrier became the first British manufacturer to produce a three-axle passenger vehicle, aided by the availability of larger pneumatic tyres,[24] and in 1926, entered into an agreement with Clough, Smith & Co. Ltd. to produce the 'Karrier-Clough' trolley-omnibus which Clough would market.[24] This arrangement continued until 1933, when Karrier began marketing the trolleybuses themselves. Despite receiving multiple orders in 1933–4, Karrier went into receivership, leading to the takeover by Humber in 1934, thus becoming part of the Rootes Group.[24] Trolleybus manufacture was moved to Rootes' Sunbeam subsidiary's factory at Wolverhampton, where it continued up until World War II.[24] During the periods in wartime, when production was allowed, only one model was produced, the W4, which could be badged either as Sunbeam or Karrier.[25] Post-war, production continued briefly before the trolleybus portion of the company was sold to Brockhouse in 1946.[25]

Lorry or bus chassis[]

  • A/40-110 cwt type (1908–)
  • B/20-110 cwt type (1910–)
  • C type (1922–34)
C 14-seat or 30 cwt (1922, 1924–5)
CK3 3 ton RSC road sweeper-collector vehicles (c.1937)
CK6 3 ton RSC road sweeper-collectorvehicles (c.1937)
CX 40 cwt (1922) public cleansing vehicle
CY 40 cwt public cleansing vehicle or 20 seat (1924–27)
CY1 (1925–)
CY2 40cwt (1928–31) low loader refuse wagon
Victor 65cwt (1932)
CY3 hand operated tipper
CVR 50-65cwt (1930–34) low-loader
CYR 60 cwt (1934) low loader refuse wagon
CYS 40 cwt
CWY 60 cwt (1926–31)
Protector 75/80cwt (1932–34)
CL 20/29 seat 60 cwt e.g. Norfolk (1926)
CY6 50cwt (1926)
CL4 30, 26, 26/29 seat (1927–29)
CL6 30 seat (1928)
CV5 32 seat (1928)
CV6 6-wheel rigid body, 65 cwt chassis (1926–)
CL R-6WH 30 seat (1927)
  • K (forward control) and SK (side) type (1922–33)
K1 60/65cwt or 28–45 seat (1922–23)
SK1 60/65cwt (1922–23)
K2 70/75/80 cwt (1922–24)
SK2 70/75/80cwt (1922–24)
K3 60 cwt or 28–54 seat (1922–25)
SK3 33/35 seat (1922–25)
K4 80/90cwt (1922–27)
SK4 80cwt (1922–25)
K5 100/110/120 cwt (1922–31)
SK5 100/110cwt (1922–25)
Consul 155cwt (1932–34)
Carrimore 10/12 ton, e.g. on K5 chassis (c.1936)
KL 30/32 seat 5 ton e.g. Stafford (1926)
K6 tractor 12 ton (1927–31)
K7 7 ton (1928–31)
KW6 8 ton (1929)
KWR6 8/9 ton (1930–33)
KWF6 8/10 ton (1930–33)
  • J type (1924–29)
JH 60/65/70 cwt (1924–27)
JK 30/32 seat 75 cwt e.g. Durham (1926)
JKL 52 or 32 seat (1927–28)
JKL FC 32 seat (1929)
  • H 18–25 seat or 50 cwt (1922–25)
  • Z 20/25 cwt (1925–27)
ZX 30 cwt or 20 seat, e.g. Devon (1926–29)
ZX2 24 seat (1927)
  • WD 2 ton (1924–26)
  • GH4 80/95cwt (1928–33)
GH5 FC 80/100/120cwt (1929–33)
Colossus 220/265cwt (1932–34)
Falcon 3 ton (1934)
Defender 5 ton (1934)
Elector 6 ton (1934)
Autocrat 6 ton (1934) forward drive
Democrat 5 ton (1934)

Bus chassis[]

WL6 6-wheel rigid chassis, 5 ton, 28 passengers single or 54 passengers double deck bus
DD6 various bus models (1929–31)
WO6 various bus models (1929–31)
RM6 100/120cwt (1931–32)
FM6 100/120cwt (1931–34)
TT tractor 12 ton (1931–33)
Cutter 20 seat 4-wheel (1928–32)
Coaster 28 seat 4-wheel (1928–35)
Chaser 4 26/35 seat 4-wheel (1928–32)
Chaser 6 26 seat (1930–5)
Clipper 40 seat 6-wheel (1928–31)
Consort 68 seat 6-wheel (1928–34)
Monitor 50 seat 4-wheel double decker (1929–34)

Trolley bus chassis[]

  • Trolley Bus (1935–)
EA3 32-4 seat single deck 4-wheel ()
E4L 326 seat single deck 4-wheel light-eight ()
E4S 32 seat single deck 4-wheel ()
E4 56 seat double deck 4-wheel ()
E6 Clough 60 seat double deck 6-wheel ()
E6A 70 seat double deck 6-wheel ()
W4 double deck 4-wheel ()

Light goods vehicles[]

  • Colt
Colt 2 ton 3 wheel tractor or RSC (1930–4)
Colt Major 4 ton 3 wheel tractor (1930–4)
Colt (1937–39)
  • Cob
Cob 50/60 cwt 3 wheel tractor (c.1930)
Cob Junior 4 ton 3 wheel tractor or RSC road sweeper-collector (1935-9)
Cob Major 4 ton 3 wheel tractor
Cob Senior 6 ton 3 wheel tractor or RSC road sweeper-collector (c.1937)
Cob Six 6 ton 3 wheel tractor (1934)
  • Gamecock
Gamecock E-series 3–4 ton 6-cylinder (1950–)
Gamecock 14 seat coach and ambulance (1954–)
Karrier-Walker 12 seat bus (1958–)
Karrier-Dennis Ambulance (1962–)
Ramillies refuse collector (1962–)
Karrier ice cream van (c.1962)
  • Bantam
Bantam 50cwt (1933–34, 36–40)
Bantam RSC road sweeper-collector (1933–39)
Bantam F-series 2–3 ton (1948–63)
Bantam FA-series 3–5 ton (1948–63)
Bantam 4–5 ton tractor (1956–)
Bantam tipper (1958–)
Bantam FB-series 3 ton (1972–)

References[]

  1. Census 1911 by FindMyPast and Free BMD
  2. Death Of Mr. H. F. Clayton. The Times, Monday, 1 April 1935; pg. 4; Issue 47027
  3. Page:558, The London Gazette Publication date:27 January 1899 Issue:27046
  4. Out and Home.—By "The Extractor." The Commercial Motor, 24 September 1908, Page 12
  5. 5.0 5.1 5.2 Karrier Motors, Limited. The Times, Tuesday, 9 March 1920; pg. 22; Issue 42354.
  6. Karrier Motors, Ltd. The Times, Monday, 21 October 1929; pg. 25; Issue 45339
  7. Company Results. The Times, Tuesday, 7 July 1925; pg. 23; Issue 44007
  8. The Karrier Motors Capital Scheme. The Times, Wednesday, 20 October 1926; pg. 24; Issue 44407
  9. Karrier Motors Scheme. The Times, Friday, 18 October 1929; pg. 24; Issue 45337.
  10. Commercial Motor Makers' Fusion. The Times, Thursday, 4 August 1932; pg. 16; Issue 46203
  11. T.S. Motors, Ltd. The Times, Saturday, 27 August 1932; pg. 15; Issue 46223
  12. The Times Tuesday, 13 September 1932; pg. 17; Issue 46237
  13. Company Results. The Times, Saturday, 26 August 1933; pg. 14; Issue 46533
  14. Negotiations Stated To Be In Progress, page16, Yorkshire Post and Leeds Intelligencer, Thursday 7 June 1934
  15. City News In Brief. The Times, Friday, 1 October 1948; pg. 9; Issue 51191
  16. "Rootes-Chrysler resource site".
  17. Mechanical Horse. page 5, Yorkshire Post and Leeds Intelligencer – Tuesday 18 November 1930
  18. A "Mechanical Horse". The Times, Thursday, 4 December 1930; pg. 5; Issue 45687.
  19. Motor Transport Show. The Times, Friday, 6 November 1931; pg. 20; Issue 45973
  20. The "Ro-Railer". The Times, Friday, 23 January 1931; pg. 11; Issue 45728
  21. "Railways, Part III". Retrieved on 17 December 2016.
  22. Information, Reed Business (23 December 1982). "New Scientist". Reed Business Information. Retrieved on 17 December 2016.
  23. L A Summers, British Railways Steam 1948–1970, Amberley Publishing, Stroud, 2014.
  24. 24.0 24.1 24.2 24.3 Lumb, Geoff (1995). British Trolleybuses: 1911–1972. Ian Allan Publishing, 81. ISBN 0711023476.
  25. 25.0 25.1 Lumb, Geoff (1995). British Trolleybuses: 1911–1972. Ian Allan Publishing, 82. ISBN 0711023476.
