A GM "old look" 5101 coach, built on a 4509 chassis.|frameless|upright=1.25|alt=]]
Yellow Coach (1940-1943)|
GMC Truck and Bus (1944-1969)
|Successor||GM New Look|
|Engine(s)||Detroit Diesel 4-71 or 6-71|
|Transmission(s)||Hydraulic or Manual|
|Length||25 ft (7.62 m), 28 ft (8.53 m), 30 ft (9.14 m), 33 ft (10.06 m), 35 ft (10.67 m), 37.75 ft (11.51 m), 40 ft (12.19 m), or 41.5 ft (12.65 m)|
|Width||96 in (2.44 m) or 102 in (2.59 m)|
113 in (2.87 m)|
The GM "old-look" bus was somewhat streamlined in appearance (resembling the PCC streetcar in styling), similar in shape to a loaf of sandwich bread, and had windows that were generally smaller than those found on more modern bus designs produced after the 1950s. Unlike most earlier buses, the GM "old-look" bus was built using a monocoque design, rather than a body-on-frame design, and it helped shepherd the change from gasoline to diesel-powered buses. Most "old-look" buses were powered with the Detroit Diesel 6-71 inline six-cylinder diesel engine, the exceptions being the shorter models that were powered by the four-cylinder version of the same diesel engine, and buses that were equipped with gasoline engines. Manual and automatic transmissions were available, with the Spicer angle-drive two-speed transmission being used on automatic-equipped buses built prior to 1948. After 1948, the 2-speed Allison V-drive transmission was used on automatic-equipped buses. In 1940 and 1942, a small number of buses were built with electric propulsion systems instead of a transmission. The "old-look" was available in several lengths ranging from 25 feet (7.6 m) to 41 feet 6 inches (12.6 m), though the most common models were 35 feet (11 m) and 40 feet (12 m) feet long. Most "old-look" buses were 96 inches (2.4 m) wide, but 102-inch-wide (2.6 m) models were available beginning in 1948. In 1946 GM began offering its Thermo-matic heating and ventilation system, and in 1952 started making suburban models (identifiable by larger passenger windows, and equipped with high-backed forward-facing seats and optional luggage racks). Beginning in 1953, air-ride suspension became standard on all but the smallest model buses, and in 1958, air conditioning was added as an available option.
In 1959, GM introduced its New-Look bus with the "fishbowl" style front window, and production stopped on all "old-look" buses other than the "second-generation" models: the 28-foot (8.5 m) TGH-3102 which was built until 1963 and the 30-foot (9.1 m) 35xx models which were built until 1969.
The model designations used for GM "old-look" buses consisted of a series of two or three letters followed by a series of four numbers (for example, TDH-4512). The letters and numbers gave a basic description of the type of bus as follows:
|Type||Fuel||Transmission||Nominal seating capacity||Series|
|T = transit bus
||D = diesel|
G = gasoline
|H = hydraulic (automatic) transmission|
M = manual transmission
E = electric propulsion
|27 = 25 feet (7.6 m)|
31 or 32 = 28 feet (8.5 m)
35 or 36 = 30 feet (9.1 m)
40 = 33 feet (10 m)
45 = 35 feet (11 m)
48 = 37 feet 9 inches (11.5 m)
51 = 40 feet (12 m)
54 or 55 = 41 feet 6 inches (12.6 m)
The following buses are organized by vehicle length (all buses are 96 inches wide unless noted). Note that Yellow Coach realigned all models to series 05 in 1941.
Following World War 2, cities in the Soviet Union needed a modern transit bus. Agreement was reached to build GM's model TDH-3610 under license (but with diesel-electric propulsion, similar to that used for the TDE-40xx models), and production was assigned to ZiS (Zavod imeni Stalina: literally Plant named after Stalin) where it became their model number 154. The ZIS-154 was first assembled with a locally-manufactured Yaroslavl YAZ-204 diesel, but supply problems caused ZiS to switch to the Detroit Diesel 6-71, also built under license. Continuing issues with the reliability of the drive-train components resulted in the ZIS-154 being discontinued after only slightly more than four years of production and 1,165 units.
In some places these buses were nicknamed "lightning" because of the rapid acceleration provided by the diesel-electric drive.
In an attempt to overcome the problems of the ZIS-154, the less-technically-advanced ZIS-155 was designed. In 1949 Moscow's Central Auto Repair Workshop (ЦАРМ: Центральные авторемонтные мастерские) constructed a batch of shortened ZIS-154 bodies and mounted them on modified ZIS-150 truck chassis. One source suggests that the "Moscow" prototypes had shrouds over the rear wheels, a more-stylized front wheel cut-out, and a larger radiator. The prototypes were successful, and full-scale production began at ZIS.
The most noticeable difference between the ZIS-154 and the ZIS-155 was the placement of the doors: since the ZIS-155 had a front engine, the doors were moved to behind the axles. The driver's compartment was completely separated from the passenger saloon by a bulkhead, so the buses were two-man operated, with a rear entrance and front exit. The 154 employed unibody construction, while the 155 was body-on-frame.
Besides being the standard city bus in the Soviet Union in the 1950s, a large quantity were exported to other Eastern-block countries, and were know to have been used in Warsaw, Berlin, Ulan Bator and Beijing. A twelve-seat long-distance version was also built. In Moscow a number of withdrawn units were rebuilt as trailers, but they were not a success as the ZIS-155 was underpowered and therefore had difficulty pulling a fully-loaded trailer, too.
From 1955 the ZIS-155 was equipped with an alternator instead of a generator, the first Soviet bus to do so. After Stalin fell out of favour, the ZIS plant was renamed in 1956 to Zavod Imeni Likhacheva (ZIL), after its former director Ivan Alekseevich Likhachev. As a result, late-production 155s were designated as ZIL-155.
|Seats + Standees||34 + ?||23 + 21||28 + 22||38 + 18|
|Length||9.50 m (31 ft 2 in)||8.07 m (26 ft 6 in)||8.26 m (27 ft 1 in)||10.365 m (34 ft 0.1 in)|
|Width||2.50 m (98 in)||2.50 m (98 in)||2.50 m (98 in)||2.615 m (103.0 in)|
|Height||2.49 m (98 in)||3.11 m (122 in)||2.49 m (98 in)||3.67 m (144 in)|
|Wheelbase||5.46 m (215 in)||3.94 m (155 in)?||4.09 m (161 in)||6.00 m (236 in)|
|Rear Overhang||?||2.85 m (112 in)||2.70 m (106 in)||?|
|Weight||8,000 kg (18,000 lb)||6,000 kg (13,000 lb)||6,290 kg (13,900 lb)||9,250 kg (20,400 lb)|
|Engine|| DD 6-71|
|Horsepower|| 110 @ 2000 rpm|
|90||95 @ 2800 rpm||80 kW|
