Ford TW-15
Ford TW10 4wd tractor
Model history
Model introduced 1983
Model discontinued 1990
Model status Discontinued
No. produced Unknown
Preceded by Ford TW-10
Engine Specification
Engine make Ford
Engine model ?
Fuel type Diesel
Power hp 133
105 (drawbar), 120(PTO)
Power kW 100 kW
Governed rpm {{{governedrpm}}}
Displacement cu in /(litre) 401 cu inches (6.6 litres)
No. of Cylinders 4
Bore in (mm) 4.4 inches (112 mm)
Stroke in (mm) 4.4 inches (112 mm)
Cooling system Water
Naturally aspirated, Turbo or Supercharged Yes
Transmission Details
Transmission type Dual-power
Gearbox make Ford
Forward 16 (24) (Optional)
Reverse 4 (6)
Drive 2-WD or 4-WD versions
General Data
Linkage Category Cat II
Lift capacity (lb/kg) 6,000 lb (2700 kg)
Tyre Sizes (std/options)
Front 10 x 16 (2-wd)
? x ? (4-wd)
Rear 18.4 x 38
Tractor Dimensions
Length (inches/metres) 145 inches (4450 mm)
Width (inches/meters) 104.5 inches (2650 mm)
Height (inches/meters) 116 inches (2950 mm) (cab)
Weight (nominal) lb/kg 12,700 lbs (5,700 kg)
Wheelbase 110 inches (2780 mm)
Cab Details
Cab Make Ford
Type of Cab Ford 'Bubble cab' MkII
Other info
Factories Basildon, UK
Plow rating Unknown
Nebraska Tests No. ?
Notes 4-WD option
This box: view · talk

The Ford TW-15 was introduced in 1983 as part of the update to the TW series and replaced the Ford TW-10 model. The TW-15 was discontinued in 1990 when it was replaced by the New Holland model range.

Model history[]

Specification[]

Options[]

Prices[]

Serial numbers[]

Preservation[]

These relatively modern 'Classic' models are starting to be collected by owners for Showing and road run use and occasional work during the busy times of year in their farming enterprise. Also there are some smaller contractors who find a well maintained / restored example offers better value than investing in an over specified modern electronic controlled tractor as the relative simplicity allows them to service and repair them in there own workshop.
