Manchester, United Kingdom,
Sao Bernardo do Campo, Brazil
Buenos Aires, Argentina
|Predecessor||Ford Model S|
|Successor||Ford Model A|
|Class||Full-size Ford, economy car|
2-door roadster pickup
2-door ton truck
2-door closed cab ton truck
Center door wagon
|Engine(s)||177 in3 (2.9 L) 20 hp I4|
2-speed planetary gear|
3-speed planetary gear
|Curb weight||1200 lb|
|Fuel capacity||10 US gallons (38 L)|
|Designer||Henry Ford, Childe Harold Wills, Joseph A. Galamb and Eugene Farkas|
The Ford Model T (colloquially known as the Tin Lizzie and Flivver) is an automobile that was produced by Henry Ford's Ford Motor Company from 1908 through 1927. The Model T set 1908 as the historic year that the automobile came into popular usage. It is generally regarded as the first affordable automobile, the car that "put America on wheels"; some of this was because of Ford's innovations, including assembly line production instead of individual hand crafting, as well as the concept of paying the workers a wage proportionate to the cost of the car, so that they would provide a ready made market. The first production Model T was built on September 27, 1908, at the Piquette Plant in Detroit, Michigan.
There were several cars produced or prototyped by Henry Ford from the founding of the company in 1903 until the Model T came along. Although he started with the Model A, there were not 19 production models (A through T); some were only prototypes. The production model immediately before the Model T was the Ford Model S, an upgraded version of the company's largest success to that point, the Model N. The follow-up was the Ford Model A and not the Model U. Company publicity said this was because the new car was such a departure from the old that Henry wanted to start all over again with the letter A. As it happens, the first Plymouth car (1928), built by competitor Chrysler Corporation, was named the Model U.
The Ford Model T was named the world's most influential car of the twentieth century in an international poll. Henry Ford said of the vehicle:
"I will build a car for the great multitude. It will be large enough for the family, but small enough for the individual to run and care for. It will be constructed of the best materials, by the best men to be hired, after the simplest designs that modern engineering can devise. But it will be low in price that no man making a good salary will be unable to own one - and enjoy with his family the blessing of hours of pleasure in God's great open spaces."
- 1 Characteristics
- 2 Production
- 3 Advertising, marketing, and packaging
- 4 Summary
- 5 Car clubs
- 6 Preservation
- 7 See also
- 8 References
- 9 External links
Characteristics[edit | edit source]
The Ford Model T car was designed by Childe Harold Wills and two Hungarian immigrants Joseph A. Galamb and Eugene Farkas. Also, Harry Love, C. J. Smith, Gus Degner and Peter E. Martin were part of the team. While production of the Model T began in 1908, model years range from 1909 to 1927.
Engine and means of starting[edit | edit source]
- Main article: Ford Model T engine
The Model T had a front mounted, 177 in3 (2.9 L) four-cylinder en bloc motor (that is, all four in one block, as common now, rather than in individual castings, as common then) producing 20.2 hp (15 kW) for a top speed of 40-45 mph (64–72 km/h). The small four cylinder engine was known for its L heads. According to Ford Motor, the Model T had fuel economy on the order of 13 to 21 mpg (5 to 9 kilometres per litre or 11.1 to 18.7 litres per 100 km). The engine was capable of running on gasoline, kerosene or ethanol, though the decreasing cost of gasoline and the later introduction of Prohibition in the United States made ethanol an impractical fuel.
A flywheel magneto (broadly equivalent to a modern alternator) produced low voltage alternating current to power a trembler coil, which created a high voltage current. This ignition pulse was passed to the timer (analogous to a distributor in a modern vehicle) and redistributed to the firing cylinder. Ignition timing was adjusted manually by using the spark advance lever mounted on the steering column which rotated the timer. A battery could be used for starting current: at hand-cranking speed, the magneto did not always produce sufficient current (but was initially available on early cars). A certain amount of skill and experience was required to find the optimal timing for any speed and load. When electric headlights were introduced in 1915, the magneto was upgraded to supply power for the lights and horn. In keeping with the goal of ultimate reliability and simplicity, the trembler coil and magneto ignition system was retained even after the car became equipped with a generator and battery for electric starting and lighting. Most cars sold after 1919 were equipped with electric starting, which was engaged by a small round button on the floor in front of the driver's seat.
Before starting a Model T with the hand crank, the spark had to be manually retarded or the engine might "kick back". The crank handle was cupped in the palm, rather than grabbed with the thumb under the top of the handle, so that if the engine did kick back, the rapid reverse motion of the crank would throw the hand away from the handle, rather than violently twisting the wrist or breaking the thumb. Most Model T Fords had the choke operated by a wire emerging from the bottom of the radiator where it could be operated with the left hand. This was used to prime the engine while cranking the engine slowly then starting the engine with the left hand with a rapid pull of the crank handle.
The car's 10 gallon (38 litre) fuel tank was mounted to the frame beneath the front seat; one variant had the carburetor (a Holley Model G) modified to run on ethyl alcohol, to be made at home by the self-reliant farmer. Because fuel relied on gravity to flow forward from the fuel tank to the carburetor, a Model T could not climb a steep hill when the fuel level was low. The immediate solution was often to drive up steep hills in reverse. In 1926, the fuel tank was moved forward to under the cowl on most models.
Early on the engine blocks were to be produced by the Lakeside Foundry on St. Jean in Detroit. Ford cancelled the deal before many engine blocks were produced.
While the first few hundred Model Ts had a water pump, its use was abandoned early in production. Ford opted for a cheaper and more reliable circulation system based on the thermo-syphon principle. Hot water, being less dense, would rise to the top of the engine and up into the top of the radiator, descending to the bottom as it cooled, and back into the engine. This was the direction of water flow in most makes of cars even when they did have water pumps, until the introduction of crossflow radiator designs. Water pumps were also available as an aftermarket accessory for Model T.
Transmission and drivetrain[edit | edit source]
The Model T was a rear-wheel drive vehicle. Its transmission was a planetary gear type billed as "three speed". In today's terms it would be considered a two speed, since one of the three speeds was actually reverse.
The Model T's transmission was controlled with three foot pedals and a lever that was mounted to the road side of the driver's seat. The throttle was controlled with a lever on the steering wheel. The left pedal was used to engage the gear. With the handbrake in either the mid position or fully forward and the pedal pressed and held forward the car entered low gear. When held in an intermediate position the car was in neutral, a state that could also be achieved by pulling the floor-mounted lever to an upright position. If the lever was pushed forward and the driver took his foot off the left pedal, the Model T entered high gear, but only when the handbrake lever was fully forward. The car could thus cruise without the driver having to press any of the pedals. There was no separate clutch pedal.
The middle pedal was used to engage reverse gear, and the right pedal operated the engine brake. The floor lever also controlled the parking brake, which was activated by pulling the lever all the way back. This doubled as an emergency brake.
Although it was extremely uncommon, the drive bands could fall out of adjustment, allowing the car to creep, particularly when cold, adding another hazard to attempting to start the car: a person cranking the engine could be forced backward while still holding the crank as the car crept forward even though it was nominally in neutral. As the car utilised a wet clutch, this condition can also occur in cold weather where the thickened cold oil acts somewhat like an adhesive and prevents the clutch discs from slipping freely. Power reached the differential through a single universal joint attached to a torque tube which drove the rear axle; some models (typically trucks, but available for cars as well) could be equipped with an optional two speed Ruckstell rear axle shifted by a floor mounted lever which provided an underdrive gear for easier hill climbing. All gears were vanadium steel running in an oil bath.
Alternate uses of engine power[edit | edit source]
Consistent with the practical-mindedness of folk in those "make do" days, the cost of the car was rationalized by added duty. The vehicle was used much like a farm vehicle by taking off the rear wheel and using belts, etc to power commonly available belt-driven equipment of the time. An example is a wide belt, powered from the rear hub, used to move hay from the ground to the hayloft in the barn (pre-1940)
Suspension and wheels[edit | edit source]
Model T suspension employed a transversely mounted semi-elliptical spring for each of the front and rear axles, which was a solid beam axle, not an independent suspension, which still allowed a great deal of wheel movement to cope with the dirt roads of the time.
The front axle was drop forged as a single piece of vanadium steel. Ford twisted many axles eight times and sent them to dealers to be put on display to demonstrate its superiority. The Model T did not have a modern service brake. The right foot pedal applied a band around a drum in the transmission, thus stopping the rear wheels from turning. The previously mentioned parking brake lever operated band brakes on the outside of the rear brake drums.
Wheels were wooden artillery wheels, with steel welded-spoke wheels available in 1926 and 1927.
Tires were pneumatic 30 in (76 cm) in diameter, 3.5 in (8.9 cm) wide in the rear, 2 in (5 cm) in the front. The old nomenclature for tire size changed from 30×3 to 21" (rim diameter) × 4.50 (tire width).[clarification needed]
All tires in this time period used a balloon-like structure called an "inner tube" to hold the pressurized air. "Tubeless" tires were not generally in use until much later.
Wheelbase was 99 inches; while standard tread width was 56 in (142 cm), 60 in (152 cm) tread could be obtained on special order, "for Southern roads".
Design changes[edit | edit source]
There were few major changes throughout the life of this model; early ones had a brass radiator and headlights. The horn and numerous small parts were also brass. Many of the early cars were open-bodied touring cars and runabouts, these being cheaper to make than closed cars. Prior to the 1911 model year (when front doors were added to the touring model), U.S.-made open cars did not have an opening door for the driver. Later models included closed cars (introduced in 1915), sedans, coupes and trucks. The chassis was available so trucks could be built to suit. Ford also developed some truck bodies for this chassis, designated the Model TT. The headlights were originally acetylene lamps made of brass (commonly using Prest-O-Lite tanks), but eventually the car gained electric lights, initially powered from the magneto until the electrical system was upgraded to a battery, generator and starter motor, when lighting power was switched to the battery source.
The Model T originally employed some advanced technology, for example, its use of vanadium steel. Its durability was phenomenal, and many Model Ts and their parts were still in use 80 years later.
Colors[edit | edit source]
By 1918, half of all cars in America were Model Ts. However, it was a monolithic bloc; as Ford wrote in his autobiography, "Any customer can have a car painted any color that he wants so long as it is black". Until the development of the assembly line, which mandated black because of its quicker drying time, Model Ts were available in other colors including red. Model Ts in different colors were produced from 1908 to 1914, and then again from 1926 to 1927. It is often stated that Ford chose black because the paint dried faster than other colored paints available at the time, and a faster drying paint would allow him to build cars faster since he would not have to wait as long for the paint to dry. The technical aspect of this explanation is plausible, as a black paint will absorb the most light and convert it to heat which will help the solvents in the paint to evaporate,[citation (source) needed] however Ford engineering documents suggest black was chosen because it was cheap and durable. Over thirty different types of black paint were used on various parts of the Model T. These were formulated to satisfy the different means of applying the paint to the various parts, and they had distinct drying times, depending on the part, the paint, and the method of drying.
Production[edit | edit source]
Mass production[edit | edit source]
The Model T was the first automobile mass produced on assembly lines with completely interchangeable parts, marketed to the middle class. The needed factory worker knowledge and skills were reduced to one of 84 areas.
When introduced, the T used the building methods typical at the time, assembly by hand, and production was small. Ford's Piquette plant could not keep up with demand for the Model T, and only 11 cars were built there during the first full month of production. More and more machines were used to reduce the complexity within the 84 defined areas. In 1910, after assembling nearly 12,000 Model Ts, Henry Ford moved the company to the new Highland Park complex.
As a result, Ford's cars came off the line in three minute intervals, much faster than previous methods, increasing production by eight to one (requiring 12.5 hours before, 93 minutes afterwards), while using less manpower. By 1914, the assembly process for the Model T had been so streamlined it took only 93 minutes to assemble a car. That year Ford produced more cars than all other automakers combined. The Model T was a great commercial success, and by the time Henry made his 10 millionth car, 10 percent of all cars in the entire world were Fords. In fact, it was so successful that Ford did not purchase any advertising between 1917 and 1923; in total, more than 15 million Model Ts were manufactured, more than any other model of its day. Model T production was finally surpassed by the Volkswagen Beetle on February 17, 1972.
Henry Ford's eccentric approach to research and development meant few changes to the vehicle were made over its lifetime; he believed the Model T was all the car a person would, or could, ever need. As other companies offered comfort and styling advantages, at competitive prices, the Model T lost market share. Eventually, on May 26, 1927, Ford Motor Company ceased production and began the changeovers required to produce the Model A.
Model T engines continued to be produced until August 4, 1941. Almost 170,000 engines were built after car production stopped. Replacement engines were required to continue to service already produced vehicles. Racers and enthusiasts, forerunners of modern hot rodders, used the Model T's block to build popular and cheap racing engines, including Cragar, Navarro, and famously the Frontenacs ("Fronty Fords") of the Chevrolet brothers, among many others.
In 2002, Ford built a final batch of 6 Model Ts as part of their 2003 centenary celebrations. These cars were assembled from remaining new components and other parts produced from the original drawings. The last of these 6 was used for publicity purposes in the UK.
Price[edit | edit source]
The standard 4-seat open tourer of 1909 cost $850 (equivalent to $20,709 today), when competing cars often cost $2,000-$3,000 (equivalent to $48,726-$73,089 today);[citation (source) needed] in 1913, the price dropped to $550 (equivalent to $12,181 today), and $440 in 1915 (equivalent to $9,521 today). Sales were 69,762 in 1911, 170,211 in 1912, 202,667 in 1913, 308,162 in 1914, and 501,462 in 1915. In 1914, an assembly line worker could buy a Model T with four months' pay.
By the 1920s, the price had fallen to $300 (equivalent to $3,289 today) because of increasing efficiencies of assembly line technique and volume. Henry employed vertical integration of the industries needed to create his cars. He specified how to make the wood crates that outside suppliers used to ship him parts. Then he disassembled the crates and used the preformed wood pieces in the bodies of his cars. He also used wood scraps to make charcoal and sold it under the brand name Kingsford, still a leading brand of charcoal.
First world car[edit | edit source]
The Ford Model T was the first automobile built by various countries simultaneously since they were being produced in Canada and in Manchester, England starting in 1911 and were later assembled in Germany, Argentina , France, Spain, Denmark, Norway, Belgium, Brazil, Mexico and Japan.
Advertising, marketing, and packaging[edit | edit source]
Ford created a massive publicity machine in Detroit to ensure every newspaper carried stories and ads about the new product. Ford's network of local dealers made the car ubiquitous in virtually every city in North America. As independent dealers, the franchises grew rich and publicized not just the Ford but the very concept of automobiling; local motor clubs sprang up to help new drivers and to explore the countryside. Ford was always eager to sell to farmers, who looked on the vehicle as a commercial device to help their business. Sales skyrocketed—several years posted 100% gains on the previous year.
Sales passed 250,000 in 1914. By 1916, as the price dropped to $360 for the basic touring car, sales reached 472,000.
Summary[edit | edit source]
Ford was launched in a converted factory in 1903 with $28,000 (equivalent to $682 thousand today) in cash from twelve investors, most notably John and Horace Dodge (who would later found their own car company). During its early years, the company produced just a few cars a day at its factory on Mack Avenue in Detroit, Michigan. Groups of two or three men worked on each car from components made to order by other companies. Henry Ford was 40 years old when he founded the Ford Motor Company, which would go on to become one of the world's largest and most profitable companies, as well as being one to survive the Great Depression. As one of the largest family-controlled companies in the world, the Ford Motor Company has been in continuous family control for over 100 years.
Car clubs[edit | edit source]
Cars built before 1919 are classed as veteran cars and later models as vintage cars. Today, three main clubs exist to support the preservation and restoration of these cars: The Model T Ford Club International, the Model T Ford Club of America and the combined clubs of Australia. With many chapters of clubs around the world, the Model T Ford Club of Victoria has a membership with a considerable number of uniquely Australian cars. (Australia produced its own car bodies and therefore many differences occurred between the Australian bodied tourers and the US/Canadian cars). Many steel Model T parts are still manufactured today, and even fiberglass replicas of their distinctive bodies, which are popular for T-bucket style hot rods (as immortalized in the Jan and Dean surf music song "Bucket T," which was later recorded by The Who).
In 2008, there was an around Australia trip organised by various members of the NSW portion of the Combined model T clubs of Australia (http://www.modelt.2ya.com/). Along the trip the members of the club met the likes of Malcolm Douglas and others. The trip lasted just over 6 months, all of this time the members ate, drank and slept in their cars that they had modified for the trip. They left Sydney on 20th, April and made it all the way to Echuca in Victoria for the 100 year anniversary of the model T Ford. People come from all over Australia, New Zealand and America for the trip to one major city in Australia that is held every 3 years, they stayed for a week in Echuca and participated in various activities organised by the Victoria club and eventually moved on to go home and see their families back in Sydney on the 9th, October 2008.
In The Music Man by Meredith Wilson Model T's are blamed for changes in society and the life of travelling salesmen. "Why it's the Model T Ford made the trouble, made the people/ Want to go, want to git, want to git, want to git up and go/ Seven, eight, nine, ten, twelve, fourteen, twenty-two, twenty-three miles to the county seat/ Yes Sir Yes Sir/ Who's gonna patronize a little bitty two-by-four kind of store any more?"
Preservation[edit | edit source]
In the UK there are a number of Model T Fords either in original condition or restored in various levels up to Concourse standard. Some of these vehicles are original UK machines but others are modern imports from the USA or other places with a Dryer climate that results in less rust attaching the vehicle than in the UK's often damp conditions.
UK Examples[edit | edit source]
These are a few of the cars & other Model T based vehicles in the UK; (please expand the list)
- The British Commercial Vehicle Museum has a Model T Van on display.
Cars in other countries[edit | edit source]
Add details here please;
See also[edit | edit source]
- List of Ford vehicles
- Ford Model T engine
- Henry Ford
- Ford Motor Company
- Aeroford - a British copy of the Model T
- New Zealand RM class (Model T Ford) - a 1925 experimental railcar based on a Model T body (on wikipedia)
References[edit | edit source]
- Ford also attempted a buy on time program to aid sales, resembling that of the German Kdf-Wagen (forerunner of the Volkswagen Type 1). Ford's plan was not a success, either.
- Early Ford - models from the years 1903 - 1908; p. 5.
- Joyrides | Car of the Century? Ford's Model T, of course.
- Robert Lacey. Ford: The Men and the Machine. ISBN 978-0316511667.
- David Reynolds. America, Empire of Liberty: A New History. ISBN 978-1846140563.
- "History Lesson: Hungary Celebrates the Ford Model T". Edmunds.com. Retrieved on 2008-02-29.
- Reynold M. Wik, Henry Ford Grass Roots America, 1972.
- Clymer, Floyd. Treasury of Early American Automobiles, 1877-1925 (New York: Bonanza Books, 1950), p. 100.
- media.ford.com Model T Facts.
- "Ford Model T reaches 100". The Telegraph (2008-07-25). Retrieved on 2008-08-11.
- "Ethanol: Introduction". Journey to Forever. Retrieved on 2008-08-11.
- 1926 - Model T Ford Club of America.
- Clymer, p. 37.
- Clymer, p. 100.
- Ford, My Life and Work, 1922, p. 72.
- McCalley, Bruce W. (1994). Model T Ford: The Car That Changed the World. Krause Publications. ISBN 0-87341-293-1.
- detnews.com | Michigan History.
- Ward, Ian, ed. The World of Automobiles (London: Orbis, 1974), Volume 13, p. 1562.
- Georgano, G. N. Cars: Early and Vintage, 1886-1930. (London: Grange-Universal, 1985).
- www.auto-historia.com History of Ford Motors Argentina - Retrieved on 19 November 2008.
- Celebrating the Ford Model T, only 100 years young!, (in Spanish) accessed 22 September 2008.
- Lewis 1976, pp. 41–59.
- Jameson, Eric scholar of Automotive Studies.
