 McCormick Farmall 130, 1957 | |
| Model history | |
|---|---|
| Model introduced | 1956 |
| Model discontinued | 1958 |
| Model status | Discontinued Discontinued |
| No. produced | 9,709 |
| Preceded by | Farmall 100 |
| Superseded by | Farmall 140 |
| Engine Specification | |
| Engine make | International |
| Engine model | C-123 |
| Fuel type | gasoline |
| Power hp | 22 belt, 20 drawbar |
| Governed rpm | 1400 |
| Displacement cu in /(litre) | 123 ci |
| No. of Cylinders | 4 |
| Bore in (mm) | 3.125" |
| Stroke in (mm) | 4" |
| Cooling system | water |
| Naturally aspirated, Turbo or Supercharged | NA |
| Transmission Details | |
| Transmission type | sliding gear |
| Gearbox make | International |
| Forward | 4 |
| Reverse | 1 |
| Drive | 2-WD |
| General Data | |
| Linkage Category | "Fast-Hitch" 2-point |
| Tyre Sizes (std/options) | |
| Front | 5.00-15 4-ply |
| Rear | 11-24 4-ply |
| Tractor Dimensions | |
| Length (inches/metres) | 107" |
| Width (inches/meters) | 56" |
| Height (inches/meters) | 65" |
| Weight (nominal) lb/kg | 2650 lb |
| Turning circle (nominal) inches/meters | 17 ft |
| Wheelbase | 71" |
| Other info | |
| Factories |
Tractor Works, Chicago, Illinois, USA Louisville, Kentucky, USA |
| Plow rating | 1-16" or 2-12" |
| Nebraska Tests No. | 617 |
| Approximate Cost new in (year) | $1950 (1958) |
The Farmall 130 was built by International Harvester from 1956 to 1958 in Chicago, Illinois, USA and Louisville, Kentucky, USA.
Model History[]
- For Company history see
- Main article: International Harvester
- For high-clearance version see: Farmall 130 High Clearance
- For industrial version see: International 130
For 1957 the Hundred-series (100. 200, 300, etc.) became the 30/50-series (130, 230, 350, 450, etc.). All models were restyled with a new 2-tone paint scheme, although the sheet metal was unchanged. Harvester Red was still used for the body and chassis but a new Harvester White was applied to the grill and wheels and the hood sides under the Farmall lettering. The McCormick brand name lettering had become so small as to be almost invisible. The Farmall 130 was mechanically almost identical to the the Farmall 100 it replaced, except that the compression ratio of the engine was increased, giving the tractor a little more hp.
Tractor Comparison[]
Other makes and models competing most closely with the Farmall 130 were the Minneapolis-Moline BG and Oliver Super 44, although both were slightly more powerful than the Farmall. The Massey-Harris Pacer was somewhat smaller and less powerful. The Ford 501 was built in the offset style, like the Farmall, but was quite a bit heavier and more powerful. Another small tractor competing with the Farmall for some uses was the standard-tread John Deere 40. During 1958 International Harvester replaced the Farmall 130 with the slightly more powerful Farmall 140.
| Make & model | Pto hp | Weight (lb) | Price ($) |
|---|---|---|---|
| McCormick Farmall 130 | 22 | 2650 | 1950 (1958) |
| Ford 501 | 33 | 3530 | |
| John Deere 40 Standard | 25 | 2950 | 1521 (1954) |
| Massey-Harris Pacer | 19 | 1915 | 1418 (1957) |
| Minneapolis-Moline BG | 28 | 2880 | 1710 (1957) |
| Oliver Super 44 | 25 | 2386 | 1935 (1959) |
| McCormick Farmall 140 | 23 | 2720 | 2400 (1962) |
Note: Some specifications and prices for comparison tables from [1] and [2]
Timeline[]
- 1956 - Farmall 130 replaced Farmall 100
- 1958 - Farmall 140 replaced Farmall 130
Factory locations[]
Specification[]
See Infobox for basic details
- 123 ci 4-cylinder gasoline engine
- 4-speed transmission
- Adjustable front axle
- Electric starting and lights
- Touch Control hydraulics
- 1-point Fast Hitch implement attachment
- Standard tires
- Front: 5.00-15 4-ply
- Rear: 9-24 4-ply
Variations and Options[]
- Distillate engine
- Non-adjustable front axle
- Belt pulley
- Pto
- Hydra-Creeper slow speed attachment
- Optional tires
- Front: 4.00-15 or 6.00-16 4-ply
- Rear: 10-24 or 11-24 4-ply
Serial Numbers Information[]
| Year | Serial no. run startstart[3] |
Serial no. run End[3] |
Number Built | Notes |
|---|---|---|---|---|
| 1956 | 501 | 1119 | 619 | Number built calculated from serial number range |
| 1957 | 1120 | 8362 | 7243 | |
| 1958 | 8363 | 10209 | 1847 | |
| Total built | 9709 | |||
Preservation[]
No detailed information of any of these tractors in preservation is currently available on here.
- Do you know of any examples to add to list below ?
| Make + Model No. | Reg No. (if known) |
Serial No. | Build-Date | Engine-Type/Make | Owner (if known) |
Photo | Were seen/Featured in | Other info |
|---|---|---|---|---|---|---|---|---|
| Farmall 130 | unknown | sn 1407 | ? | ? | owner ? |
|
Photos uploaded by User | |
| Farmall 130 | unknown | sn 545 | ? | ? | Pennsylvania | |||
|
||||||||
| Please add any tractor with known reg or serial no. with Photo if possible. | ||||||||
| Make & model | reg no | serial no | date built | engine | owner |
|
seen at | misc info |
| Create a page (link) for an individual tractor by linking the reg or serial number using reg number or serial number in the relevant column. Then once saved click the red link to start the new page and add info on that tractor. | ||||||||
Gallery[]
Add extra photos here please.
Farmall 130 examples
Replace with your image
Caption here
Freshly restored by Burch Store Tractors, Burlington NC sn 7582
