David Brown 880 Implematic
Image needed LHB
A DB 880
Model history
Model introduced 1961
Model discontinued 1965
Model status Discontinued
No. produced Unknown
Preceded by David Brown 950
Superseded by David Brown 770
Engine Specification
Engine make David Brown
Fuel type Diesel
Power hp 32 (PTO)
Power kW 23.9
Governed rpm {{{governedrpm}}}
No. of Cylinders 4 cylinder till 12,685 built
3-cylinder from 1964
Naturally aspirated, Turbo or Supercharged Na
Transmission Details
Transmission type Unknown
Gearbox make David Brown
Forward 12
Reverse 4
Drive 2-WD
General Data
Linkage Category Cat I
Tyre Sizes (std/options)
Front 5.5-16
Rear 12.4/11-28
Tractor Dimensions
Weight (nominal) lb/kg 1723 kg (3800 lbs)
Other info
Factories Meltham, W. Yorkshire, UK
Plow rating Unknown
Nebraska Tests No. Unknown
This box: view · talk

The David Brown 880 Implematic was built by David Brown from 1961 to 1965 in Meltham, West Yorkshire, England. It featured a 32 hp (24 kW) David Brown engine.

Model History Edit

For Company history see
Main article: David Brown

The history of this item is unknown. Can you help add any history for it ?

Timeline Edit

Factory locations Edit

  • Meltham, West Yorkshire, UK

Specification Edit

  • See Info box details

Variations and Options Edit

Initially Red with Yellow grill & exhaust, and 4 cylinder engine but after 12,685 built engine changed to 3-cylinder model.

  • Low clearance option
  • Narrow version
  • 11/49 (high speed) or 9/50 (low speed) final drive option.
  • A fabricated front axel introduced in 1963 from serial no, 355065
  • Height control added from sn 355341

Serial Numbers Information Edit

  • Can you add any details of build numbers ?
Serial Numbers and Year of Manufacture data[1]
Year Serial run Number Built Notes (Total built xyz).
1961 First built (Red & Yellow)
1963 Fabricated front axle added from sn 355065
1964 362382 last 4 cylinder (August 1964)
1964 521001 swap to 3 cylinder
Height control added
1965 527521 19207 built Last 880 built October 1965
year serial no Number built Notes


  • 880 Livedrive £721.7s.6d in 1964 price list.[2]

Preservation Edit

No information on any of these tractors in preservation is available.

(Do you know of any examples to list ?
List of Preserved David Brown 880 Implematic tractors
view  talk  edit
Make + Model No.
Reg No.
(if known)
Serial No. Build-Date Engine-Type/Make Owner
(if known)
Photo Were seen/Featured in Other info
Image needed LHB

Image needed LHB

Please add any tractor with known reg or serial no. with Photo if possible.
Create a page (link) for an individual tractor by linking the reg or serial number using reg number or serial number in the relevant column. Then once saved click the red link to start the new page and add info on that tractor.

Gallery Edit

See also Edit


References / Sources Edit

External Links Edit
