Axial cross section of Carnot's heat engine. In this diagram, abcd is a cylindrical vessel, cd is a movable piston, and A and B are constant–temperature bodies. The vessel may be placed in contact with either body or removed from both (as it is here).[1]

A Carnot heat engine[2] is a hypothetical engine that operates on the reversible Carnot cycle. The basic model for this engine was developed by Nicolas Léonard Sadi Carnot in 1824. The Carnot engine model was graphically expanded upon by Benoît Paul Émile Clapeyron in 1834 and mathematically elaborated upon by Rudolf Clausius in the 1857s and 66s from which the concept of entropy emerged.

Every single thermodynamic system exists in a particular state. A thermodynamic cycle occurs when a system is taken through a series of different states, and finally returned to its initial state. In the process of going through this cycle, the system may perform work on its surroundings, thereby acting as a heat engine.

A heat engine acts by transferring energy from a warm region to a cool region of space and, in the process, converting some of that energy to mechanical work. The cycle may also be reversed. The system may be worked upon by an external force, and in the process, it can transfer thermal energy from a cooler system to a warmer one, thereby acting as a refrigerator or heat pump rather than a heat engine.

In the adjacent diagram, from Carnot's 1824 work, Reflections on the Motive Power of Fire,[3] there are "two bodies A and B, kept each at a constant temperature, that of A being higher than that of B. These two bodies, to which we can give or from which we can remove the heat without causing their temperatures to vary, exercise the functions of two unlimited reservoirs of caloric. We will call the first the furnace and the second the refrigerator.”[4] Carnot then explains how we can obtain motive power, i.e. “work”, by carrying a certain quantity of heat from body A to body B.

Modern diagram Edit

Carnot heat engine 2

Carnot engine diagram (modern) - where heat flows from a high temperature TH furnace through the fluid of the "working body" (working substance) and into the cold sink TC, thus forcing the working substance to do mechanical work W on the surroundings, via cycles of contractions and expansions.

The previous image shows the original piston-and-cylinder diagram used by Carnot in discussing his ideal engines. The figure at right shows a block diagram of a generic heat engine, such as the Carnot engine. In the diagram, the “working body” (system), a term introduced by Clausius in 1850, can be any fluid or vapor body through which heat Q can be introduced or transmitted to produce work. Carnot had postulated that the fluid body could be any substance capable of expansion, such as vapor of water, vapor of alcohol, vapor of mercury, a permanent gas, or air, etc. Although, in these early years, engines came in a number of configurations, typically QH was supplied by a boiler, wherein water was boiled over a furnace; QC was typically a stream of cold flowing water in the form of a condenser located on a separate part of the engine. The output work W here is the movement of the piston as it is used to turn a crank-arm, which was then typically used to turn a pulley so to lift water out of flooded salt mines. Carnot defined work as “weight lifted through a height”.


Carnot's theorem Edit

Main article: Carnot's theorem (thermodynamics)
Real vs Carnot

real ideal engines (left) compared to the Carnot cycle (right). The entropy of a real material changes with temperature. This change is indicated by the curve on a T-S diagram. For this figure, the curve indicates a vapor-liquid equilibrium (See Rankine cycle). Irreversible systems and losses of heat (for example, due to friction) prevent the ideal from taking place at every step.

Carnot's theorem is a formal statement of this fact: No engine operating between two heat reservoirs can be more efficient than a Carnot engine operating between the same reservoirs.

This maximum efficiency $ \eta $ is defined to be:

$ \eta=\frac{W}{Q_H}=1-\frac{T_C}{T_H} \quad\quad\quad\quad\quad\quad\quad\quad\quad(1) $

where

$ W $ is the work done by the system (energy exiting the system as work),
$ Q_H $ is the heat put into the system (heat energy entering the system),
$ T_C $ is the absolute temperature of the cold reservoir, and
$ T_H $ is the absolute temperature of the hot reservoir.

A corollary to Carnot's theorem states that: All reversible engines operating between the same heat reservoirs are equally efficient.

In other words, maximum efficiency is achieved if and only if no new entropy is created in the cycle. Otherwise, since entropy is a state function, the required dumping of heat into the environment to dispose of excess entropy leads to a reduction in efficiency. So Equation (1) gives the efficiency of any reversible heat engine.

The Coefficient of Performance (COP) of the heat engine is the reciprocal of its efficiency.

Efficiency of real heat engines Edit

Carnot realized that in reality it is not possible to build a thermodynamically reversible engine, so real heat engines are less efficient than indicated by Equation (1). Nevertheless, Equation (1) is extremely useful for determining the maximum efficiency that could ever be expected for a given set of thermal reservoirs.

Although Carnot's cycle is an idealisation, the expression of Carnot efficiency is still useful. Consider the average temperatures,

$ \langle T_H \rangle = \frac{1}{\Delta S} \int_{Q_{in}} TdS $
$ \langle T_C \rangle = \frac{1}{\Delta S} \int_{Q_{out}} TdS $

at which heat is input and output, respectively. Replace TH and TC in Equation (1) by <TH> and <TC> respectively.

For the Carnot cycle, or an equivalent, <TH> is the highest temperature available and <TC> the lowest. For other less efficient cycles, <TH> will be lower than TH, and <TC> will be higher than TC. This can help illustrate, for example, why a reheater or a regenerator can improve the thermal efficiency of steam power plants — and why the efficiency of combined-cycle power plants (which incorporate gas turbines operating at even higher temperatures) exceeds that of conventional steam plants.

According to the second theorem, "The efficiency of the carnot engine is independent of the nature of the working substance".

See also: Heat engine (efficiency and other performance criteria)
